1kW Junior Fresnel
ARRIHeads
The 1kW tungsten Fresnel lamp head is an essential component of any motion-picture lighting package.
Product Details
| Manufacturer | ARRI |
|---|---|
| Model | 1kW Junior Fresnel |
| Dimensions (mm)(in) | 345 x 255 x 22513.58 x 10.04 x 10.04 |
| Operation | Manual |
| Type | Fresnel |
| Power Draw (W) | 1000 |
| Supply Connector | 1 x 16A Ceeform In |
| Lux @ 3M (3200K) | 12142 (Spot) / 2033 (Flood) |
| Beam Angle Min (°) | 11 |
| Beam Angle Max (°) | 54 |
| High Speed Capability | No |
| Protection Rating | IP20 |
| Mounting | 16mm/28mm combo |
| Panalux SKU | IAA04A0 |
| Part Number | L0.79500.N |
| Weight (kg)(lbs) | 5.75 12.68 |
